Size

7000*2500*1500 (mm)

Payload

30000KG

Main beam

Heavy duty I beam.

Side beam

140mm channel beam

Axles

2 * 13ton capacity  (Brand optional)

Suspension

Mechanical suspension (Air suspension optional)

Leaf spring

10pcs

Tire

12R22.5  8pcs  (Other size optional)

Rim

9.00-22.5  8pcs   (Other size optional)

Kin pin

2’’/3.5’’ bolt type

Landing gear

28 Ton two speed

Twist locks

4 pcs

Braking system

Double air chamber ,brake valve,32L air tanks ;ABS optional

Electrical

LED light , 7 ways ,24V

Painting

Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting
